The advantages of our design

● Over 80 PCB design engineers

● Technical exchange in the industry has accumulated rich experience

● "New" technology, in our case is "mature" technology

● Perfect training system, sufficient talent reserve

● More than 6 years of industry experience per capita, senior staff 10-16 years

● More than 1000 types of PCB design experience every year







Shorten product launch cycle

To shorten the time to market, our expectation is to shorten the design cycle by 30-50%

  • Super size: Team effect of 80 engineers

  • Parallel design: Can provide multiple parallel 7x24 service

  • Design reuse: mature module rule reuse, shorten delivery time

  • Senior team: professional team and senior engineer

  • Each person has hundreds of PCB design experience



Our philosophy


(1)Do the right thing the first time

  • Do things right the first time, reduce R&D times, and reduce R&D costs

  • The product is quickly introduced to the market to get the first chance



(2)Reduce costs for customers

  • Rigorous process, design specifications, in line with the mainstream PCB board manufacturers and assembly manufacturers of the process requirements

  • Design parameters are not only suitable for the R&D stage, but also take full account of the mass production characteristics

  • Have own PCB factory and Assembly plant, familiar with various production parameters



Ability to design


Project

Parameter

Project

Parameter

Max PCB design layers

30L

Min via holes

6mil(laser holes is 4mil)

Max PIN

100000+

Max number of BGA

50+

Max number of connections

76000+

Min BGA PIN spacing

0.3mm

Min design track

2.5mil

Max BGA PIN number

4500

Min design space

2.5mil

Max speed signal

56G-PAM4
